WHSG24002G Base Gigabit SMD à port unique - T PIN24 non - Transformateur LAN PoE
WHSG24002G Single Port SMD Gigabit Base-T PIN24 non-PoE LAN Transformer
Request a Quote
Leave your details and we will send a tailored volume quote.
Our sales team will contact you within 1 business day.
Contact Sales
Reach our sales team for pricing and lead time.
Submitted
We have received your request. Our sales team will contact you within 1 business day.
Pour une assistance technique, veuillezcliquez sur le bouton ci-dessous pour ajouter le service client or visitez la page de demande d'échantillonpour remplir le formulaire. Nous vous servirons dans les plus brefs délais.
E-mail du support technique : fae.thorne@voohu.cn Téléphone : +86 400-1048-018
Pour plus de détails, veuillez visiter leCentre de téléchargementpour obtenir des documents ou cliquez sur le bouton ci-dessous pour ajouter le service client. Nous vous servirons dans les plus brefs délais.
Pour les commandes de petits-volumes, vous pouvez passer des commandes directement surBoutique VOOHU. Nous prenons en charge les factures TVA générales/spéciales avec un processus pratique et efficace.
Pour une assistance technique ou des demandes d’échantillons, veuillezcliquez sur le bouton ci-dessouspour ajouter un service client ouvisitez la page de demande d'échantillonpour remplir le formulaire. Nous vous servirons dans les plus brefs délais.
Email du service client : song.lei@voohu.cn Téléphone : +86 180 2130 1120
The WHSG24002G suits indoor Gigabit ports where the component temperature stays between 0 °C and +70 °C.Typical uses are desktop switches, the LAN ports of set-top boxes and routers, office IP cameras and Gigabit management ports inside a rack. The WHSG24002G is a single-port, non-PoE 100/1000 BASE-T transformer, so the port has to be powered locally.
Where the equipment must power up below 0 °C or sit in an outdoor enclosure, move to the wide-temperature part in the same package, which keeps the same land pattern and pin assignment. Other options are listed in the100/1000 BASE-T range.
No. The datasheet assigns no DC balance current capability to the centre taps of the WHSG24002G, so they cannot be used as a supply path.There is no current item among its eleven electrical entries. Terminate the centre taps according to the reference design for the target PHY.
Note that the 8 mA DC bias quoted on the OCL line is not a permitted load current – it is a direct current superimposed during the inductance measurement, so that the figure reflects the core with a DC component present. Where the port has to deliver power, send VOOHU the target PoE wattage, current and temperature range and we will reselect from the100/1000 BASE-T range.
Decide on operating temperature: take theWHSG24002TGfor -40 °C to +85 °C, or the WHSG24002G where 0 °C to +70 °C is enough and usually better on cost and availability.The two are identical value for value on mechanical dimensions, suggested land pattern, pin-to-net assignment and every electrical figure, so switching between them changes neither the electrical design nor the board layout.
One point is worth watching: the storage range of the WHSG24002G is wider than its own operating range. That is a warehousing and shipping condition, not grounds for widening the operating window. Both parts sit in the100/1000 BASE-T range.
