WHSG48008-3PG Dual Ports SMD Gigabit Base-T PIN48 4PPoE LAN Transformer
Request a Quote
Leave your details and we will send a tailored volume quote.
Our sales team will contact you within 1 business day.
Contact Sales
Reach our sales team for pricing and lead time.
Submitted
We have received your request. Our sales team will contact you within 1 business day.
For technical assistance, pleaseclick the button below to add customer service or visit the sample request pageto fill out the form. We will serve you as soon as possible.
Technical Support Email: fae.thorne@voohu.cn Phone: +86 400-1048-018
For more details, please visit theDownload Centerto get documents or click the button below to add customer service. We will serve you as soon as possible.
For purchases and small-volume orders, please contact our sales team. We support VAT general/special invoices with a convenient and efficient process.
For technical assistance or sample requests, pleaseclick the button belowto add customer service orvisit the sample request pageto fill out the form. We will serve you as soon as possible.
Customer Service Email: song.lei@voohu.cn Phone: +86 180 2130 1120
The WHSG48008-3PG datasheet states both scopes: each channel supports 600 mA of DC current, and full channels support 1200 mA.
A Gigabit port is built from four differential pairs, and each differential pair is one channel; two channels, one out and one back, make a pairset, so a Gigabit port is two pairsets — which is exactly why the full-channel figure is twice the per-channel one. Budget port power from these two numbers as printed, and do not multiply 600 mA by the number of channels: the current follows the port's return loop, not a count of windings. The same convention applies across the100/1000 BASE-T range.
Because open-circuit inductance is measured under a DC bias, and the bias has to sit near the real supply operating point for the figure to mean anything.
The WHSG48008-3PG states 350 µH Min at 15 mA bias, where non-PoE parts usually state the same figure at 8 mA. When comparing PoE parts, read the bias condition alongside the inductance — comparing the numbers alone compares two different operating conditions. Bias conditions vary across the100/1000 BASE-T range.
Pins 1–24 are the chip side, named TCT1–TCT8 and TD1±–TD8±; pins 25–48 are the cable side, named CMT1–CMT8 and TX1±–TX8±, with Chip Side and Cable Side printed group by group on the drawing.
Orient the WHSG48008-3PG with pins 1–24 toward the PHY and 25–48 toward the RJ45 and both ports' pairs run straight through. The part is surface-mount, 27.80 × 12.20 mm and 7.50 mm Max high, supplied 350 pieces to a reel. Not every part in the100/1000 BASE-T rangeprints these side labels.
