WHS16037TG SMD 10/100Base à port unique - TX PIN16 non - Transformateur LAN PoE
WHS16037TG Single Port SMD 10/100Base-TX PIN16 non-PoE LAN Transformer
Request a Quote
Leave your details and we will send a tailored volume quote.
Our sales team will contact you within 1 business day.
Contact Sales
Reach our sales team for pricing and lead time.
Submitted
We have received your request. Our sales team will contact you within 1 business day.
Pour une assistance technique, veuillezcliquez sur le bouton ci-dessous pour ajouter le service client or visitez la page de demande d'échantillonpour remplir le formulaire. Nous vous servirons dans les plus brefs délais.
E-mail du support technique : fae.thorne@voohu.cn Téléphone : +86 400-1048-018
Pour plus de détails, veuillez visiter leCentre de téléchargementpour obtenir des documents ou cliquez sur le bouton ci-dessous pour ajouter le service client. Nous vous servirons dans les plus brefs délais.
Pour les commandes de petits-volumes, vous pouvez passer des commandes directement surBoutique VOOHU. Nous prenons en charge les factures TVA générales/spéciales avec un processus pratique et efficace.
Pour une assistance technique ou des demandes d’échantillons, veuillezcliquez sur le bouton ci-dessouspour ajouter un service client ouvisitez la page de demande d'échantillonpour remplir le formulaire. Nous vous servirons dans les plus brefs délais.
Email du service client : song.lei@voohu.cn Téléphone : +86 180 2130 1120
Land pattern, outline and internal structure are identical; each upgrades a different axis — the WHS16037TG upgrades temperature, theWHS16037-2KGupgrades isolation.
The WHS16037TG is rated -40 °C to +85 °C and keeps the standard 1500 VAC isolation grade; the other raises isolation to 2500 VAC and keeps the 0 °C to +70 °C range. Every other item matches. In other words, wide temperature rules out 2500 VAC and vice versa, which is a decision to take early in selection.
Where the transformer's own location powers up below 0 °C, or runs above +70 °C for long stretches.
The deciding figure is the temperature at the part's location, not the cabinet or room ambient — a surface-mount part sits on the board surface and runs well above inlet temperature near a power supply or downstream in the airflow. 100M ports are common in small industrial equipment: fanless gateways, DIN-rail modules, outdoor front ends. The WHS16037TG is rated -40 °C to +85 °C; other grades sit in the10/100 BASE-T range.
No. The WHS16037TG is a non-PoE part: its centre taps serve only as AC termination and common-mode reference and carry no DC supply current.
The 8 mA in the datasheet is the DC bias applied while measuring open-circuit inductance, not current available for powering anything. A port that has to deliver power over the cable needs a part whose datasheet states a current capability and the applicable IEEE class, chosen at selection time. PoE-rated parts are grouped in theGigabit range.
