WHSG24701AG Single Port SMD Gigabit Base-T PIN24 LAN Transformer

WHSG24701AG Single Port SMD Gigabit Base-T PIN24 LAN Transformer

Category: LAN Transformer
WHSG24701AG LAN Transformer perspective view
Left click: Rotate | Right click: Pan | Scroll: Zoom
Get a Quote or Samples
›
Product Datasheet
›
+ Add to Inquiry
›
Support
›
3D Model
›
PCB Layout / Package
›
Contact Us
›
VOOHU sales contact QR code
Buy Online
›

Request a Quote

Leave your details and we will send a tailored volume quote.

Leave a phone number or an email. Either one is enough.

Our sales team will contact you within 1 business day.

Contact Sales

Reach our sales team for pricing and lead time.

Contact Sales
Sales Hotline: +86 133 5804 1040
Email: voohu@voohuele.com
✓

Submitted

We have received your request. Our sales team will contact you within 1 business day.

Urgent? Message us on WhatsApp: +86 133 5804 1040

Product Parameters
Débit de données 100/1000 Base-T
Mode d’installation SMD
Ports 1 port
Broches 24
Pas 1.27mm
Température de fonctionnement 0 à 70 °C
Vt (V (RMS)) 1500
PoE Sans PoE
Solution
Ethernet
SPE
CAN
RS485
LVDS
Isolated SPI
PoE
Push-Pull Converter
Technical Resources and Design Support
We also provide professional technical support and document download services, including: package library download, datasheet download, reference circuit design materials, 3D model download, etc.
For technical assistance, please message us on WhatsApp or visit the sample request page to fill out the form. We will serve you as soon as possible.
Technical Support Email: voohu@voohuele.com WhatsApp: +86 133 5804 1040
Quality Certifications
VOOHU is ISO 9001 and ISO 14001 certified. Our main product lines are RoHS and REACH compliant, backed by third-party test reports, and selected RJ45 connector models carry a CE certificate.
For certificates and test reports, please visit the Download Center, or contact us and we will send you the documents you need.
ISO9001 ISO14001 RoHS REACH CE
Get a Quote or Samples
Whether you need sample testing, bulk purchasing or customized solutions, our sales team will respond quickly.
For samples, pricing or technical assistance, please visit the sample request page to fill out the form, or message us on WhatsApp. We will serve you as soon as possible.
Email: voohu@voohuele.com WhatsApp: +86 133 5804 1040
Get a Quote or Samples › Contact Us ›
VOOHU sales contact QR code

WHSG24701AG Cross Reference

VOOHU WHSG24701AG is a functional alternative to Pulse Electronics H5007NL — verify with samples in your design. See the evaluation reports below for the differences.

Manufacturer Part Number Relationship Evaluation
Pulse Electronics H5007NL Functional alternative · verify with samples H5007NL evaluation report

Based on VOOHU replacement evaluations. Check both datasheets and validate with samples before switching.

FAQ LAN Transformer: WHSG24701AG
A

Every published electrical and mechanical field matches value for value — the same 17.55 × 12.20 mm body, 1.27 mm pitch, 24-pin single-port surface-mount package, down to an identical recommended land pattern; the difference is on the schematic, where the WHSG24701AG draws three magnetic elements per channel against two on the WHSG24701G.

Either part will fit the same board, but the internal structure differs and EMC has to be re-verified on the finished unit after a change.

A

The body is 17.55 × 12.20 mm, 17.55 × 16.00 mm including leads, 6.00 mm high, on a 1.27 mm pitch, with 0.100 mm coplanarity across 24 terminations.

The WHSG24701AG shares one recommended land pattern with several parts in the same family — the largest common-footprint group in the 100/1000 BASE-T range, which lets one board move between capability grades. A shared land pattern is not the same as interchangeability, though: some parts differ in internal element count and others in pin assignment, so check placement against the target part's own drawing.

A

The datasheet carries no PoE current item, so the WHSG24701AG should not be selected as a PoE part and its port has to be powered locally.

Where power over the cable is required, move at selection time to a part whose datasheet states a current capability — preferably one that also names the scope (for example "each channel supports N mA"), so the port power budget does not depend on interpreting the figure. PoE-rated parts are grouped in the 100/1000 BASE-T range.
