WHSM24P02-1PG Single Port SMD 10G PIN24 PoE LAN Transformer
Request a Quote
Leave your details and we will send a tailored volume quote.
Our sales team will contact you within 1 business day.
Contact Sales
Reach our sales team for pricing and lead time.
Submitted
We have received your request. Our sales team will contact you within 1 business day.
For technical assistance, pleaseclick the button below to add customer service or visit the sample request pageto fill out the form. We will serve you as soon as possible.
Technical Support Email: fae.thorne@voohu.cn Phone: +86 400-1048-018
For more details, please visit theDownload Centerto get documents or click the button below to add customer service. We will serve you as soon as possible.
For purchases and small-volume orders, please contact our sales team. We support VAT general/special invoices with a convenient and efficient process.
For technical assistance or sample requests, pleaseclick the button belowto add customer service orvisit the sample request pageto fill out the form. We will serve you as soon as possible.
Customer Service Email: song.lei@voohu.cn Phone: +86 180 2130 1120
Yes. The WHSM24P02-1PG datasheet states "IEEE802.3at compliant performance – 720mA Current Capability", and that 720 mA is the capability of each magnetic channel's centre tap.Size four balanced copper paths against 720 mA each, taking the width from your actual copper thickness and permitted rise.
For a port-level total on the WHSM24P02-1PG, confirm the figure with us before design freeze rather than multiplying 720 mA by the number of channels.
No. The WHSM24P02-1PG quotes common-mode rejection as -20 dB typ from 1 to 500 MHz, 5 dB below the -25 dB typ used by most parts in this speed class.Both are typical values rather than limits, so neither belongs in a worst-case budget as it stands.
Carrying a figure across from another part number would understate the margin by a further 5 dB. Take the number from the part you are actually fitting, and if the project has to sign off against guaranteed limits, raise it during selection of the10G BASE-Tpart.
Not recommended. The WHSM24P02-1PG operates from 0 °C to +70 °C, and the inside of an outdoor enclosure in direct sun regularly exceeds that ceiling.Its -40 °C to +85 °C storage range is what the part survives unpowered and cannot be used as an operating condition.
For a wide-temperature 10G powered port, move to a part whose operating range covers -40 °C to +85 °C, such as theWHSM24015T0. If the target PoE class is higher than that part provides, send us the per-port current and temperature you need and we will reselect.
