LAN Transformer
WHSM24P02-1PG 10GBASE-T PoE+ LAN Transformer
Single-port 10GBASE-T LAN transformer (Ethernet transformer): 24-pin SMD, 1500 Vrms isolation, PoE+ (up to 720 mA). Operating temperature 0 to +70 °C.
- Data rate
- 10GBASE-T
- Ports
- Single port
- Mounting
- SMD
- Isolation voltage
- 1500 Vrms
- PoE
- PoE+ (up to 720 mA)
- Operating temperature
- 0 to +70 °C
Left click: Rotate | Right click: Pan | Scroll: Zoom
Product Datasheet
Get a Quote or Samples
+ Add to Inquiry
Support
3D Model
PCB Layout / Package
Contact Us
Buy Online
Buy Online
When you click Get a Quote or Samples or Add to Inquiry, part number WHSM24P02-1PG is filled in automatically.
Request a Quote
Leave your details and we will send a tailored volume quote.
Our sales team will contact you within 1 business day.
Contact Sales
Reach our sales team for pricing and lead time.
Sales Hotline: +86 133 3865 5578
Email: voohu@voohuele.com
✓
Submitted
We have received your request. Our sales team will contact you within 1 business day.
01Specifications
WHSM24P02-1PG specifications
Key attributes
ParameterValue
Data rate
10GBASE-T
Ports
Single port
Operating temperature
0 to +70 °C
PoE
PoE+ (up to 720 mA)
Mounting
SMD
Pins
24
Pitch
1.0 mm
Electrical
ParameterValue
Isolation voltage
1500 Vrms
Values from published data for this part (parameters, FAQ and evaluation report). The datasheet prevails.
WHSM24P02-1PGNeed samples, or a value that is not in this table? Ask our FAE team.
Get a Quote or Samples
+ Add to Inquiry
02Applications
Where WHSM24P02-1PG is used
- Switches and routers
- Wireless access points
- IP cameras
- Industrial control devices
Typical application
The transformer isolates the PHY from the cable and couples the TX and RX differential pairs to the RJ45 jack.
Center-tap biasing on the PHY side depends on the PHY type (voltage-mode or current-mode).
Typical application for reference. Follow the PHY vendor's reference design.
Design notes
- 01Connect the center taps according to your PHY type.Voltage-mode and current-mode PHYs need different center-tap biasing; a mismatch can break auto-negotiation.Check with your PHY →
- 02Terminate the line-side center taps with a Bob Smith network.It gives common-mode noise a defined path to chassis ground and helps EMC.
- 03Add line-side surge protection for outdoor or long-cable ports.Residual surge energy through the transformer can still damage the PHY.Troubleshooting guide →
Reference designs by application:Industrial ControlSecurity MonitoringData Communication
WHSM24P02-1PGNot sure it fits your PHY and layout? An engineer can check your design.
Get a Quote or Samples
+ Add to Inquiry
03Documents
Datasheet, CAD and reports
-
WHSM24P02-1PG Datasheet (PDF)2024-11-25 · This part Download ↓
-
3D model (STEP)2026-06-24 · This part Download ↓
-
PCB Layout / Package2025-12-29 · This part Download ↓
-
LAN Transformer Reliability TestLatest · Product family View →
-
LAN Transformer EU RoHS ReportLatest · Product family View →
-
REACH SVHC test reportLatest · Communication electronic components View →
WHSM24P02-1PGNeed another file format, or samples to test? Ask our FAE team.
Get a Quote or Samples
+ Add to Inquiry
04Quality
Quality and compliance
DocumentNo.Issued / tested byDateApplies toActions
Certificate
Certificate · Company
ISO 9001:2015No. 19826Q02503R101
Quality management systemBeijing Xinjiyuan Certification Co., Ltd.Valid 2026-10-17 to 2029-10-16
19826Q02503R101
Beijing Xinjiyuan Certification Co., Ltd.
Valid2026-10-17 to 2029-10-16
Company
View PDF →
Verify →
Scope: R&D and sales of precision electronic connectors
Certificate
Certificate · Company
ISO 14001:2015No. 19826E01323R101
Environmental management systemBeijing Xinjiyuan Certification Co., Ltd.Valid 2026-10-17 to 2029-10-16
19826E01323R101
Beijing Xinjiyuan Certification Co., Ltd.
Valid2026-10-17 to 2029-10-16
Company
View PDF →
Verify →
Scope: R&D and sales of precision electronic connectors
Test report
Test report · LAN transformers
EU RoHSNo. WTH26H06190301C
2011/65/EU and (EU) 2015/863, 10 substancesWaltek Testing Group HCT (Shenzhen) Co., Ltd.Issued 2026-07-31
WTH26H06190301C
Waltek Testing Group HCT (Shenzhen) Co., Ltd.
Issued2026-07-31
LAN transformers
View PDF →
Test report
Test report · Communication electronic components
REACH SVHCNo. WTH26H06167853C
253 substancesWaltek Testing Group HCT (Shenzhen) Co., Ltd.Issued 2026-07-01
WTH26H06167853C
Waltek Testing Group HCT (Shenzhen) Co., Ltd.
Issued2026-07-01
Communication electronic components
View PDF →
ISO certificates cover VOOHU's management systems. RoHS and REACH test reports cover tested samples of each product family.
05Ordering
Ordering and delivery
06Compare
Same-series Comparison
Red marks values that differ from this part; data from the published parameters of each part.
Data rate
10GBASE-T
10GBASE-T
10GBASE-T
Mounting
SMD
SMD
SMD
Ports
Single port
Single port
Single port
Pins
24
24
24
Pitch
1.0 mm
1.0 mm
1.0 mm
Operating temperature
0 to +70 °C
0 to +70 °C
0 to +70 °C
Isolation voltage
1500 Vrms
1500 Vrms
1500 Vrms
PoE
PoE+ (up to 720 mA)
4PPoE (up to 2000 mA)
Not PoE rated
WHSM24P02-1PGNot sure which part in the series fits? Ask our FAE team which one to sample.
Get a Quote or Samples
+ Add to Inquiry
07FAQ
FAQ LAN Transformer: WHSM24P02-1PG
Does the WHSM24P02-1PG support IEEE 802.3at (PoE+)?
Yes. The WHSM24P02-1PG datasheet states "IEEE802.3at compliant performance – 720mA Current Capability", and that 720 mA is the capability of each magnetic channel's centre tap. Size four balanced copper paths against 720 mA each, taking the width from your actual copper thickness and permitted rise.
For a port-level total on the WHSM24P02-1PG, confirm the figure with us before design freeze rather than multiplying 720 mA by the number of channels.
Can the common-mode rejection figure of the WHSM24P02-1PG be carried over from other 10G parts in the same range?
No. The WHSM24P02-1PG quotes common-mode rejection as -20 dB typ from 1 to 500 MHz, 5 dB below the -25 dB typ used by most parts in this speed class. Both are typical values rather than limits, so neither belongs in a worst-case budget as it stands.
Carrying a figure across from another part number would understate the margin by a further 5 dB. Take the number from the part you are actually fitting, and if the project has to sign off against guaranteed limits, raise it during selection of the 10G BASE-T part.
The WHSM24P02-1PG only operates to +70 °C — can it go in an outdoor enclosure?
Not recommended. The WHSM24P02-1PG operates from 0 °C to +70 °C, and the inside of an outdoor enclosure in direct sun regularly exceeds that ceiling. Its -40 °C to +85 °C storage range is what the part survives unpowered and cannot be used as an operating condition.
For a wide-temperature 10G powered port, move to a part whose operating range covers -40 °C to +85 °C, such as the WHSM24015T0. If the target PoE class is higher than that part provides, send us the per-port current and temperature you need and we will reselect.
