WHSM24706-2PG Single Port SMD 10G PIN24 4PPoE LAN Transformer

WHSM24706-2PG Single Port SMD 10G PIN24 4PPoE LAN Transformer

Category: LAN Transformer
WHSM24706-2PG LAN Transformer perspective view
Left click: Rotate | Right click: Pan | Scroll: Zoom
Get a Quote or Samples
›
Product Datasheet
›
+ Add to Inquiry
›
Support
›
3D Model
›
PCB Layout / Package
›
Contact Us
›
VOOHU sales contact QR code
Buy Online
›

Request a Quote

Leave your details and we will send a tailored volume quote.

Leave a phone number or an email. Either one is enough.

Our sales team will contact you within 1 business day.

Contact Sales

Reach our sales team for pricing and lead time.

Contact Sales
Sales Hotline: +86 133 5804 1040
Email: voohu@voohuele.com
✓

Submitted

We have received your request. Our sales team will contact you within 1 business day.

Urgent? Message us on WhatsApp: +86 133 5804 1040

Product Parameters
データレート 10G Base-T
実装方式 SMD
ポート数 1ポート
ピン数 24
ピッチ 1.27mm
動作温度 0~70 °C
Vt(V RMS) 1500
PoE 4PPoE(最大1200 mA)
Solution
Ethernet
SPE
CAN
RS485
LVDS
Isolated SPI
PoE
Push-Pull Converter
Technical Resources and Design Support
We also provide professional technical support and document download services, including: package library download, datasheet download, reference circuit design materials, 3D model download, etc.
For technical assistance, please message us on WhatsApp or visit the sample request page to fill out the form. We will serve you as soon as possible.
Technical Support Email: voohu@voohuele.com WhatsApp: +86 133 5804 1040
Quality Certifications
VOOHU is ISO 9001 and ISO 14001 certified. Our main product lines are RoHS and REACH compliant, backed by third-party test reports, and selected RJ45 connector models carry a CE certificate.
For certificates and test reports, please visit the Download Center, or contact us and we will send you the documents you need.
ISO9001 ISO14001 RoHS REACH CE
Get a Quote or Samples
Whether you need sample testing, bulk purchasing or customized solutions, our sales team will respond quickly.
For samples, pricing or technical assistance, please visit the sample request page to fill out the form, or message us on WhatsApp. We will serve you as soon as possible.
Email: voohu@voohuele.com WhatsApp: +86 133 5804 1040
Get a Quote or Samples › Contact Us ›
VOOHU sales contact QR code
FAQ LAN Transformer: WHSM24706-2PG
A

The WHSM24706-2PG is rated PoE Support 60W, with 1200 mA of DC balance current per magnetic channel and 2400 mA across full channels. The 2400 mA figure is what the port carries with its two channels working together – not the rating of any single centre-tap path, and not 1200 mA multiplied by the coil count.

Size four balanced copper paths against 1200 mA each, taking the width from your actual copper thickness and permitted rise. Both figures are per VOOHU's current controlled documents.

A

No. The WHSM24706-2PG operates from 0 °C to +70 °C; the -25 °C to +125 °C figure is its non-powered storage range only. A wide storage range says the part survives a larger temperature span while unpowered, which is a different thing from electrical performance and service life under power.

Design the thermal budget and the cold power-up case against 0 °C to +70 °C. If the equipment must power up below 0 °C, move to a wide-temperature part whose operating range reaches -40 °C; the choices are listed in the 10G BASE-T range.

A

Choose on how much current each centre-tap path has to carry: the WHSM24706-2PG supports 1200 mA per magnetic channel and the WHSM24P02-1PG supports 720 mA. Both figures use the same scope – DC balance current per magnetic channel – so they compare directly.

The PoE positioning differs too: PoE Support 60W on the WHSM24706-2PG, IEEE 802.3at compliant performance on the other part. Little else separates them: both operate from 0 °C to +70 °C and share the same 10G electrical block, so the choice comes down to supply capability.
