SYT511Q218AC1A8D057 100/1000M 1*1 180° non-PoE Y/G RJ45 Connector
Request a Quote
Leave your details and we will send a tailored volume quote.
Our sales team will contact you within 1 business day.
Contact Sales
Reach our sales team for pricing and lead time.
Submitted
We have received your request. Our sales team will contact you within 1 business day.
For technical assistance, pleaseclick the button below to add customer service or visit the sample request pageto fill out the form. We will serve you as soon as possible.
Technical Support Email: fae.thorne@voohu.cn Phone: +86 400-1048-018
For more details, please visit theDownload Centerto get documents or click the button below to add customer service. We will serve you as soon as possible.
For purchases and small-volume orders, please contact our sales team. We support VAT general/special invoices with a convenient and efficient process.
For technical assistance or sample requests, pleaseclick the button belowto add customer service orvisit the sample request pageto fill out the form. We will serve you as soon as possible.
Customer Service Email: song.lei@voohu.cn Phone: +86 180 2130 1120
Yes, SYT511Q218AC1A8D057 integrates 1000BASE magnetics.The schematic shows four 1CT:1CT channels with common-mode chokes, 350 µH minimum OCL and 2250 V DC primary-to-secondary hi-pot (6 s, 1 mA).
It has a yellow LED on the left and a green LED on the right.The yellow LED is 585 nm and the green is 568 nm, both rated at 20 mA. Yellow uses pins 13/14 and green uses pins 11/12.
The jack is rated for a minimum of 750 mating cycles.Contacts are 0.35 mm C5210 phosphor bronze with 6 µin gold plating in the contact area, and mating force is 23 N maximum.
