The WHSQ24302G stands 2.50 mm tall at most, over a 16.60 mm × 9.00 mm body, which makes it one of the low-profile packages in the single-port 2.5G/5G range.The conventional 24-pin package at the same data rate is 6.00 mm tall, more than double, so where a lid clearance is fixed, or the part has to sit between a daughter card and a backplane, a low-profile part is often the only one that fits.
The trade-off is a standoff of only 0.05 mm typical, so the WHSQ24302G sits almost flat against the board, leaving little room for post-reflow cleaning and little viewing angle for inspection. Confirm both against the line process when selecting it. Other options are listed in the2.5G/5G BASE-T range.
No. The datasheet of the WHSQ24302G assigns no DC balance current capability to the centre taps – there is no current item among its eleven electrical entries, so the taps cannot be used as a supply path.Terminate the centre taps as the reference design for the target PHY requires.
Note that the single-port 2.5G/5G parts which do publish PoE current, theWHSQ24702-1PTGand theWHSQ24706-2PTG, sit in the taller conventional package rather than the low-profile outline of the WHSQ24302G, so moving to one of them means redoing the layout. Where a port is both height-constrained and has to deliver power, send VOOHU the height limit, the steady current expected in each centre-tap path and the temperature range.
A reel of the WHSQ24302G holds 1500 pcs on a Ø330 mm reel.The conventional 24-pin package at the same data rate holds 350 pcs on a reel of the same diameter, so the thinner low-profile body carries more than three times as many parts per reel. That changes how often the line reloads and how a small pilot build is stocked.
Confirm inner and export carton quantities against the order. The carrier tape and reel dimensions are printed in full on the WHSQ24302G datasheet and can be handed straight to placement programming.
