WHSM48701G Dual Ports SMD 10G PIN48 non-PoE LAN Transformer

WHSM48701G Dual Ports SMD 10G PIN48 non-PoE LAN Transformer

Category: LAN Transformer
WHSM48701G LAN Transformer perspective view
Left click: Rotate | Right click: Pan | Scroll: Zoom
Get a Quote or Samples
›
Product Datasheet
›
+ Add to Inquiry
›
Support
›
3D Model
›
PCB Layout / Package
›
Contact Us
›
VOOHU sales contact QR code
Buy Online
›

Request a Quote

Leave your details and we will send a tailored volume quote.

Leave a phone number or an email. Either one is enough.

Our sales team will contact you within 1 business day.

Contact Sales

Reach our sales team for pricing and lead time.

Contact Sales
Sales Hotline: +86 133 5804 1040
Email: voohu@voohuele.com
✓

Submitted

We have received your request. Our sales team will contact you within 1 business day.

Urgent? Message us on WhatsApp: +86 133 5804 1040

Product Parameters
Datenrate 10G Base-T
Montageart SMD
Ports 2 Ports
Pins 48
Rastermaß 1.27mm
Betriebstemperatur 0 bis 70 °C
Vt (V (RMS)) 1500
PoE Ohne PoE
Solution
Ethernet
SPE
CAN
RS485
LVDS
Isolated SPI
PoE
Push-Pull Converter
Technical Resources and Design Support
We also provide professional technical support and document download services, including: package library download, datasheet download, reference circuit design materials, 3D model download, etc.
For technical assistance, please message us on WhatsApp or visit the sample request page to fill out the form. We will serve you as soon as possible.
Technical Support Email: voohu@voohuele.com WhatsApp: +86 133 5804 1040
Quality Certifications
VOOHU is ISO 9001 and ISO 14001 certified. Our main product lines are RoHS and REACH compliant, backed by third-party test reports, and selected RJ45 connector models carry a CE certificate.
For certificates and test reports, please visit the Download Center, or contact us and we will send you the documents you need.
ISO9001 ISO14001 RoHS REACH CE
Get a Quote or Samples
Whether you need sample testing, bulk purchasing or customized solutions, our sales team will respond quickly.
For samples, pricing or technical assistance, please visit the sample request page to fill out the form, or message us on WhatsApp. We will serve you as soon as possible.
Email: voohu@voohuele.com WhatsApp: +86 133 5804 1040
Get a Quote or Samples › Contact Us ›
VOOHU sales contact QR code
FAQ LAN Transformer: WHSM48701G
A

Two. The WHSM48701G is a 48-pin dual-port 10G BASE-T transformer, so one part covers two ports. Against two single-port 24-pin devices it uses less board area and fewer placements, which suits designs with high port density.

The magnetic channels for both ports of the WHSM48701G sit in one package, so route and terminate each differential pair on its own as you would with separate parts. Other single and dual-port options are in the 10G BASE-T range.

A

No. The datasheet assigns no DC balance current capability to the centre taps of the WHSM48701G, so the taps on neither port can be used as a supply path. The WHSM48701G provides signal transformation and isolation for two 10G BASE-T ports, and the ports are powered by the equipment itself.

If either port has to deliver power, move to a part that publishes a DC balance current figure, such as the single-port WHSM24P03-2PG. For a dual-port part with PoE, send us the per-port current, port count and temperature you need and we will reselect.

A

The WHSM48701G suits indoor dual-port 10G equipment where the component temperature stays between 0 °C and +70 °C. Typical uses are twin switch uplinks, dual-port server and NAS adapters, and 10G aggregation cards inside racks. The WHSM48701G carries no PoE rating, so both ports are powered by the equipment itself.

The -40 °C to +85 °C storage range is what the part survives unpowered and is not an operating condition; for power-up below 0 °C or long-term use in an outdoor enclosure, choose a part rated over the wide temperature range.
