SYT111B002BA2A1D 90° side insertion 1*1 Tab Down 10/100M LED G/Y Shield Tabs DIP RJ45

Homepage / Products

SYT111B002BA2A1D RJ45 MagJack

Single-port right-angle shielded RJ45 jack (8P8C modular jack): tab down, green / yellow LEDs, through-hole (DIP), shield tabs, integrated Ethernet magnetics (MagJack). Rated −40 to +85 °C.

Orientation: 90° (right angle)
Ports: 1 × 1
Tab: Down
LED: Green / Yellow
Integrated magnetics: Yes
Operating temperature: −40 to +85 °C

SYT111B002BA2A1D Network Connector (RJ45/RJ11) product image 1

Product Datasheet Get a Quote or Samples + Add to Inquiry Alternative PartsAlternative to HanRun HR911105A Support 3D Model PCB Layout / Package Contact Us

Buy Online

Free samples for selected parts
Lead time typically 7–10 days
Reply within 1 business day

Quality and compliance

Certificate ISO 9001

Certificate ISO 14001

Test report EU RoHS

Test report REACH

When you click Get a Quote or Samples or Add to Inquiry, part number SYT111B002BA2A1D is filled in automatically.

01Specifications

SYT111B002BA2A1D specifications

Key attributes

ParameterValue

Orientation 90° (right angle)

Ports 1 × 1

Positions / contacts 8P8C

Tab Down

LED Green / YellowGreen (left) 568 nm, yellow (right) 585 nm; 20 mA, VF: green 1.85–2.45 V, yellow 1.7–2.2 V

Integrated magnetics Yes

Data rate 10/100BASE-TX

PoE Not PoE rated

Mounting DIP

Shield tabs Yes

EMI gasket No

Operating temperature −40 to +85 °C

Electrical

ParameterValueTest condition / Note

Turns ratio 1CT:1CT TX and RX, ±2%

OCL 350 µH min 100 kHz, 100 mV, 8 mA DC bias

Insertion loss −1.0 dB max 1–100 MHz

Return loss −20 dB min 1–10 MHz; −16 dB at 10–30 MHz, −12 dB at 30–60 MHz, −10 dB at 60–80 MHz (all min)

Crosstalk −40 dB min 1–30 MHz; −35 dB at 30–60 MHz, −30 dB at 60–100 MHz (all min)

Common-mode rejection −30 dB min 1–100 MHz

Isolation voltage 1500 VAC / 2250 VDC 6 s, 1 mA, primary to secondary

Mechanical

ParameterValue

Durability 750 cycles min

Mating force 23 N max

Storage temperature −40 to +85 °C

Soldering Wave solder, peak 260 ± 5 °C5 s max at peak

Materials and compliance

ParameterValue

Housing PBT, UL94V-0, black

Terminal holder PBT, UL94V-0, black

Contacts Phosphor bronze (C5210), T=0.35 mm6 µin gold on contact area

Shield Brass (C2680), T=0.20 mmNickel-plated, all areas

Compliance REACH, RoHS compliantThird-party test reports

Values from the SYT111B002BA2A1D datasheet (rev. A0) and the published parameters. The datasheet prevails.

SYT111B002BA2A1DNeed samples, or a value that is not in this table? Ask our FAE team. Get a Quote or Samples + Add to Inquiry

02Cross reference

SYT111B002BA2A1D as an alternative to HanRun HR911105A

Request a replacement review

VOOHU SYT111B002BA2A1D is a functional alternative to HanRun HR911105A — verify with samples in your design. See the evaluation reports below for the differences.

BrandPart No.CompatibilityKey differencesEvidence

BrandHanRun Part No.HR911105A CompatibilityFunctional alternative · verify with samples Key differences— EvidenceEvaluation report

Based on VOOHU replacement evaluations. Check both datasheets and validate with samples before switching.

03Applications

Where SYT111B002BA2A1D is used

Switches and routers
Industrial controllers
IP cameras and NVRs
Embedded boards

Typical application

The jack integrates the Ethernet magnetics: the PHY connects to it directly, and the transformer and common-mode termination sit inside the jack.

Check the datasheet for the centre-tap wiring your PHY needs and match the LED pins to the PHY's LED outputs.

Typical application for reference. Follow the PHY vendor's reference design.

Works with

Design notes

01Check tab orientation and LED positions against the enclosure opening.Tab Up / Tab Down and LED placement are the most common selection errors for RJ45 jacks.Check my layout
02Bond the shield to chassis ground according to your grounding scheme.A floating or poorly bonded shield can make radiated emissions worse.EMC troubleshooting
03For PoE or isolation, the magnetics decide — not the jack.A jack without magnetics provides neither PoE nor isolation by itself; choose a PoE-rated LAN transformer or a jack with integrated PoE magnetics.See LAN transformers

Reference designs by application:Industrial Control Security Monitoring Data Communication

SYT111B002BA2A1DNot sure it fits your PHY and layout? An engineer can check your design. Get a Quote or Samples + Add to Inquiry

04Documents

Datasheet, CAD and reports

Download Center

SYT111B002BA2A1D Datasheet (PDF)2025-02-06 · This part Download
3D model (STEP)2025-02-06 · This part Download
PCB Layout / Package2025-02-06 · This part Download
RJ45 Connector Reliability TestLatest · Product family View
RJ45 EU RoHS ReportLatest · Product family View
REACH SVHC test reportLatest · Communication electronic components View

SYT111B002BA2A1DNeed another file format, or samples to test? Ask our FAE team. Get a Quote or Samples + Add to Inquiry

05Quality

Quality and compliance

DocumentNo.Issued / tested byDateApplies toActions

Certificate Certificate · Company ISO 9001:2015No. 19826Q02503R101 Quality management systemBeijing Xinjiyuan Certification Co., Ltd.Valid 2026-10-17 to 2029-10-16

19826Q02503R101 Beijing Xinjiyuan Certification Co., Ltd. Valid2026-10-17 to 2029-10-16 Company View PDF Verify Scope: R&D and sales of precision electronic connectors

Certificate Certificate · Company ISO 14001:2015No. 19826E01323R101 Environmental management systemBeijing Xinjiyuan Certification Co., Ltd.Valid 2026-10-17 to 2029-10-16

19826E01323R101 Beijing Xinjiyuan Certification Co., Ltd. Valid2026-10-17 to 2029-10-16 Company View PDF Verify Scope: R&D and sales of precision electronic connectors

Test report Test report · RJ45 connectors EU RoHSNo. WTH26H08256842R1C 2011/65/EU and (EU) 2015/863, 10 substancesWaltek Testing Group HCT (Shenzhen) Co., Ltd.Issued 2026-09-24

WTH26H08256842R1C Waltek Testing Group HCT (Shenzhen) Co., Ltd. Issued2026-09-24 RJ45 connectors View PDF

Test report Test report · Communication electronic components REACH SVHCNo. WTH26H06167853C 253 substancesWaltek Testing Group HCT (Shenzhen) Co., Ltd.Issued 2026-07-01

WTH26H06167853C Waltek Testing Group HCT (Shenzhen) Co., Ltd. Issued2026-07-01 Communication electronic components View PDF

Test report Test report · Product family Reliability test report

— — — Product family View PDF

ISO certificates cover VOOHU's management systems. RoHS and REACH test reports cover tested samples of each product family.

06Ordering

Ordering and delivery

06.1

Samples

Samples are available for evaluation, and selected parts are free of charge. Our FAE team will be glad to confirm the options for your project.

Get a Quote or Samples

06.2

Small quantities

Buy online at VOOHU Shop

07Compare

Same-series Comparison

Red marks values that differ from this part; data from the published parameters of each part.

Parameter SYT111B002BA2A1DThis part SYT111B002DB2A1D SYT111B002GWA7S

Orientation 90° (right angle) 90° (right angle) 90° (right angle)

Ports 1 × 1 1 × 1 1 × 1

Tab Down Down Down

Integrated magnetics Yes Yes Yes

Data rate 10/100BASE-TX 10/100BASE-TX 10/100BASE-TX

PoE Not PoE rated Not PoE rated Not PoE rated

LED Green / Yellow Green / Yellow No

Mounting DIP DIP SMT

Shield tabs Yes Yes Yes

EMI gasket No Yes No

Operating temperature −40 to +85 °C −40 to +85 °C −40 to +85 °C

SYT111B002BA2A1DNot sure which part in the series fits? Ask our FAE team which one to sample. Get a Quote or Samples + Add to Inquiry

08FAQ

SYT111B002BA2A1D FAQ

Does SYT111B002BA2A1D have integrated magnetics?

Yes. SYT111B002BA2A1D integrates the Ethernet magnetics.

Check the datasheet for the rated data rate and whether the magnetics are PoE-rated before using it in a PoE design.

What does Tab Down mean for SYT111B002BA2A1D?

Tab Down describes where the latch sits relative to the PCB.

With Tab Up the latch faces away from the board; with Tab Down it faces the board. Choose the orientation that matches your enclosure opening and LED placement, and check the mirrored pinout before swapping one for the other.

How do I get samples of SYT111B002BA2A1D?

Samples are available for evaluation, and selected parts are free of charge. Our FAE team will be glad to confirm the options for your project.

Use the form below; the part number is filled in automatically.
