WH491U019D0S00 SFP Connector
When you click Get a Quote or Samples or Add to Inquiry, part number WH491U019D0S00 is filled in automatically.
Request a Quote
Leave your details and we will send a tailored volume quote.
Our sales team will contact you within 1 business day.
Contact Sales
Reach our sales team for pricing and lead time.
Submitted
We have received your request. Our sales team will contact you within 1 business day.
01Specifications
WH491U019D0S00 specifications
Values are taken from published parameters; the datasheet prevails.
02Documents
Datasheet, CAD and reports
-
WH491U019D0S00 Datasheet (PDF)Latest · This part Download ↓
-
3D model (STEP)Latest · This part Download ↓
-
Quality certificates (ISO / RoHS / REACH)Latest · All products View →
03Quality
Quality and compliance
ISO certificates cover VOOHU's management systems.
04Compare
Same-series Comparison
Red marks values that differ from this part; data from the published parameters of each part.
05FAQ
FAQ SFP Connector: WH491U019D0S00
Which transceivers does WH491U019D0S00 accept?
WH491U019D0S00 is a QSFP+ 1x1 Cage that mates with QSFP MSA-compliant transceivers. The datasheet references SFF-8663. It is a cage only, so the host connector is sourced separately.
What are the overall dimensions of WH491U019D0S00?
The cage is 58.92 mm long, 18.65 mm wide (19.00 mm at the base) and 9.70 mm tall. EMI fingers ring the front opening to seal against the panel.
Can WH491U019D0S00 be used belly to belly?
Yes. The datasheet gives separate PCB layouts for single-sided and belly-to-belly mounting. Single-sided uses twelve ø1.05 mm holes, belly-to-belly uses 24. Bezel openings are 20.00 mm × 10.15 mm on a 21.00 mm pitch.
