LAN Transformer
WHDG72K01G Gigabit LAN Transformer
Quad-port 10/100/1000BASE-T LAN transformer (Ethernet transformer): 72-pin DIP, 1500 Vrms isolation, not PoE rated. Operating temperature 0 to +70 °C.
- Data rate
- 10/100/1000BASE-T
- Ports
- Quad port
- Mounting
- DIP
- Isolation voltage
- 1500 Vrms
- PoE
- Not PoE rated
- Operating temperature
- 0 to +70 °C
Left click: Rotate | Right click: Pan | Scroll: Zoom
Product Datasheet
Get a Quote or Samples
+ Add to Inquiry
Support
3D Model
PCB Layout / Package
Contact Us
Buy Online
Buy Online
When you click Get a Quote or Samples or Add to Inquiry, part number WHDG72K01G is filled in automatically.
Request a Quote
Leave your details and we will send a tailored volume quote.
Our sales team will contact you within 1 business day.
Contact Sales
Reach our sales team for pricing and lead time.
Sales Hotline: +86 133 3865 5578
Email: voohu@voohuele.com
✓
Submitted
We have received your request. Our sales team will contact you within 1 business day.
01Specifications
WHDG72K01G specifications
Key attributes
ParameterValue
Data rate
10/100/1000BASE-T
Ports
Quad port
Operating temperature
0 to +70 °C
PoE
Not PoE rated
Mounting
DIP
Pins
72
Pitch
1.78 mm
Electrical
ParameterValue
Isolation voltage
1500 Vrms
Values from published data for this part (parameters, FAQ and evaluation report). The datasheet prevails.
WHDG72K01GNeed samples, or a value that is not in this table? Ask our FAE team.
Get a Quote or Samples
+ Add to Inquiry
02Applications
Where WHDG72K01G is used
- Switches and routers
- Wireless access points
- IP cameras
- Industrial control devices
Typical application
The transformer isolates the PHY from the cable and couples the TX and RX differential pairs to the RJ45 jack.
Center-tap biasing on the PHY side depends on the PHY type (voltage-mode or current-mode).
Typical application for reference. Follow the PHY vendor's reference design.
Design notes
- 01Connect the center taps according to your PHY type.Voltage-mode and current-mode PHYs need different center-tap biasing; a mismatch can break auto-negotiation.Check with your PHY →
- 02Terminate the line-side center taps with a Bob Smith network.It gives common-mode noise a defined path to chassis ground and helps EMC.
- 03Add line-side surge protection for outdoor or long-cable ports.Residual surge energy through the transformer can still damage the PHY.Troubleshooting guide →
Reference designs by application:Industrial ControlSecurity MonitoringData Communication
WHDG72K01GNot sure it fits your PHY and layout? An engineer can check your design.
Get a Quote or Samples
+ Add to Inquiry
03Documents
Datasheet, CAD and reports
-
WHDG72K01G Datasheet (PDF)2024-11-22 · This part Download ↓
-
3D model (STEP)2026-06-04 · This part Download ↓
-
PCB Layout / Package2026-04-14 · This part Download ↓
-
LAN Transformer Reliability TestLatest · Product family View →
-
LAN Transformer EU RoHS ReportLatest · Product family View →
-
REACH SVHC test reportLatest · Communication electronic components View →
WHDG72K01GNeed another file format, or samples to test? Ask our FAE team.
Get a Quote or Samples
+ Add to Inquiry
04Quality
Quality and compliance
DocumentNo.Issued / tested byDateApplies toActions
Certificate
Certificate · Company
ISO 9001:2015No. 19826Q02503R101
Quality management systemBeijing Xinjiyuan Certification Co., Ltd.Valid 2026-10-17 to 2029-10-16
19826Q02503R101
Beijing Xinjiyuan Certification Co., Ltd.
Valid2026-10-17 to 2029-10-16
Company
View PDF →
Verify →
Scope: R&D and sales of precision electronic connectors
Certificate
Certificate · Company
ISO 14001:2015No. 19826E01323R101
Environmental management systemBeijing Xinjiyuan Certification Co., Ltd.Valid 2026-10-17 to 2029-10-16
19826E01323R101
Beijing Xinjiyuan Certification Co., Ltd.
Valid2026-10-17 to 2029-10-16
Company
View PDF →
Verify →
Scope: R&D and sales of precision electronic connectors
Test report
Test report · LAN transformers
EU RoHSNo. WTH26H06190301C
2011/65/EU and (EU) 2015/863, 10 substancesWaltek Testing Group HCT (Shenzhen) Co., Ltd.Issued 2026-07-31
WTH26H06190301C
Waltek Testing Group HCT (Shenzhen) Co., Ltd.
Issued2026-07-31
LAN transformers
View PDF →
Test report
Test report · Communication electronic components
REACH SVHCNo. WTH26H06167853C
253 substancesWaltek Testing Group HCT (Shenzhen) Co., Ltd.Issued 2026-07-01
WTH26H06167853C
Waltek Testing Group HCT (Shenzhen) Co., Ltd.
Issued2026-07-01
Communication electronic components
View PDF →
ISO certificates cover VOOHU's management systems. RoHS and REACH test reports cover tested samples of each product family.
05Ordering
Ordering and delivery
06Compare
Same-series Comparison
Red marks values that differ from this part; data from the published parameters of each part.
Data rate
10/100/1000BASE-T
10/100/1000BASE-T
10/100/1000BASE-T
Mounting
DIP
DIP
DIP
Ports
Quad port
Quad port
Quad port
Pins
72
72
72
Pitch
1.78 mm
1.78 mm
1.78 mm
Operating temperature
0 to +70 °C
0 to +70 °C
−40 to +85 °C
Isolation voltage
1500 Vrms
1500 Vrms
1500 Vrms
PoE
Not PoE rated
Not PoE rated
Not PoE rated
WHDG72K01GNot sure which part in the series fits? Ask our FAE team which one to sample.
Get a Quote or Samples
+ Add to Inquiry
07FAQ
FAQ LAN Transformer: WHDG72K01G
WHDG72K01G or the bar-shaped 72-pin quad part — how is the choice made?
By the shape of the area the PCB can free up: the WHDG72K01G is a 34.50 × 19.00 mm block, the bar parts are 65.70 × 6.50 mm, and the two occupy completely different board footprints.
On height the WHDG72K01G is 13.50 mm Max against 12.00 mm Max for the bar; the hole size is ø0.70 mm against ø0.90 mm. Four RJ45s spread along one edge suit the bar; connectors grouped in a corner suit the block.
What is the difference between the WHDG72K01G and the WHDG72K01TG?
Land pattern, pin assignment, internal element order and electrical ratings are all the same; two temperature fields differ — the WHDG72K01G is rated 0 °C to +70 °C operating and -20 °C to +125 °C storage, the WHDG72K01TG -40 °C to +85 °C and -40 °C to +125 °C.
Both cold limits move: 40 °C on the operating end, 20 °C on the storage end.
The WHDG72K01G lists +125 °C storage — does that mean it can run hot?
No. Storage temperature covers unpowered storage and transport; powered operation is governed by the operating range, and on the WHDG72K01G that is 0 °C to +70 °C.
The two fields are unusually far apart on this part (storage runs -20 °C to +125 °C), and designing thermals against the storage limit puts the part straight outside its rating. The number that matters is the temperature at the transformer's own location, not the cabinet ambient. Wide-temperature grades are listed in the 100/1000 BASE-T range.
08Support
Talk to an engineer
01Replace your current partSend the part number you use today. An engineer compares pinout, package and electrical ratings and lists the differences.Start a replacement review →
02Match it to your PHYTell us your PHY. We check center-tap wiring, termination and the matching RJ45 jack.Check my design →
03Link drops, hi-pot or EMC failuresSend the symptoms and test conditions. Get an FAE-reviewed troubleshooting checklist.Start troubleshooting →
